EnGenius Cloud Managed ECW230 | Cloud Managed Wi-Fi 6 4×4 Indoor Wireless Access Point
Optimal Performance | Enterprise Features | Cloud Management
Product Highlights
EnGenius Cloud Managed ECW230 – Wi-Fi 6 (802.11ax) 4×4 Managed Indoor Wireless Access Point features 802.11ax technology, such as OFDMA, MU-MIMO, and spatial reuse, to expand the capabilities of Wi-Fi. The low-profile AP provides high-density support & maximum speeds of 1,148 Mbps (2.4 GHz frequency) and 2,400 Mbps (5 GHz frequency).
- Dual concurrent 802.11ax architecture & backward-compatible with 11ac/a/b/g/n client devices; 4×4 antenna
- Supports up to 2,400 Mbps in 5-GHz frequency band & 1,148 Mbps in 2.4-GHz frequency band
- 2.5 GbE realizes greater throughput and supports 802.3at & 48V PoE input for flexible installation over 100 meters (328 feet)
- Uplink and downlink of OFDMA improves transmission to APs and client devices
- Target wake time for power-saving of client & IoT devices
Standards
- IEEE 802.11ax on 2.4 GHz
- IEEE 802.11ax on 5 GHz
- Backward compatible with 802.11a/b/g/n/ac
Antenna
- 4 x 2.4 GHz: 3 dBi
- 4 x 5 GHz: 3 dBi
- Integrated Omni-Directional Antenna
Physical Interface
- 1 x 10/100/1000/2500 N-BASE-T, RJ-45 Ethernet Port
- 1 x DC Jack
- 1 x Reset Button
Wireless Security
- WPA3
- WPA2 Enterprise (AES)
- WPA2 AES-PSK
- Hide SSID in Beacons
- MAC Address Filtering, Up to 32 MACs per SSID Wireless STA (Client) Connected List
- SSH Tunnel
- Client Isolation
